Description
A semi-automatic capsule filling machine combining electrical and pneumatic control for small and medium production batches.
Technical specifications
| Operation | Semi-automatic |
|---|---|
| Catalog output | 25,000–30,000 capsules/h |
| Capsule size range | 000–5 |
| Catalog mold change time | 5–8 minutes |
| Air supply | 0.03 m³/min at 0.7 MPa |
| Vacuum pump capacity | 40 m³/h |
| Dimensions | 1,140 × 700 × 1,630 mm |
| Net weight | 380 kg |
Features
- Semi-automatic filling
- Electrical and pneumatic control
- Interchangeable capsule-size tooling
Specification note: An air compressor is required separately. Confirm power supply and included utilities when requesting a quotation.
